Moose LA 21A Active Line Array 2x10''

Ultra-Compact 2-way curvilinear array module

2-way active version

2x 10” (2.56in VC) MF + 1.4” (2.56in VC) Neodymium HF driver

Class D amplifier with integrated DSP

Universal 85-264Vac mains supply

Tech Specs

TYPE

2-way active curvilinear array element

ENCLOSURE DESIGN

Trapezoidal array enclosure

POWER OUTPUT (RMS)

700W (RMS) 1400W (Program) 2800W (Peak)

FREQUENCY RANGE

52Hz - 19,5kHz (-10dB)

NOMINAL IMPEDANCE

N/A

TRANSDUCER TYPE

2x 10" (2.56in VC) MF European transducer 1.4" (2.56in VC) Neodymium HF European transducer

DISPERSION

Horizontal: 100°

Vertical

array length-splay dependent

CROSSOVER FREQUENCY

DSP controlled with selectable presets 48KHz sampling frequency 24 bit AD/DA converter

MAX. SPL (PEAK)

135dB @ 1m

AMPLIFIER TYPE

Class D, 2-way amplifier

AMPLIFIER OUTPUT

800W + 400W (continuous)

INPUT

XLR/jack combo connector

OUTPUT

XLR/M 3p

INDICATORS

Power, signal/preset, clip

CONTROLS

Master level control, 4 selectable presets

FEATURE

Convection

AC POWER SUPPLY

Switching power supply, 85-264Vac

AC MAINS CONNECTOR

Neutrik® powerCON, Power-in (blue) / Power-out (grey)

PROTECTION

Over current and short circuit protection, thermal protection, DC output protection and HF protection (amplifier)

CONSTRUCTION

15mm brich plywood, rugged polyurea coating

GRILLE

Custom perforated metal grille with protective foam

INSTALLATION / RIGGING / FLYING

Integrated steel rigging system Ø9.8mm magnetic pins w/ stainless steel lanyard with PVC Splay angle adjustable, 8° (1° increments)

DIMENSIONS (WXDXH)

740x530x280mm 29.13x20.87x11.02in

WEIGHT

32Kg 70.55lb Faithful dynamic response and great range Integrated rigging system for stacked and flown configurations Rugged and durable 15mm birch plywood construction Powder coated custom perforated steel grille
