Moose G212A Active Subwoofer 2x12"

5th order Band-Pass Subwoofer

2x 12" (4in VC) LF EU transducers

Versatile, compact, coherent and powerful subwoofer

2400W class D, single channel amplifier

85-264Vac universal mains, SMPS, all electronic protections

Fully programmable built-in DSP, 4 selectable presets

Prepared for stacking and pole mount usage

Rugged and durable 18mm birch plywood construction

Powder coated custom perforated steel grille

Tech Specs

TYPE

Compact ACTIVE subwoofer

ENCLOSURE DESIGN

5th order Band-Pass Subwoofer

POWER OUTPUT (RMS)

1400W (AES) 2800W (Program) 5600W (Peak)

FREQUENCY RANGE

35Hz - 200Hz (-6dB)

NOMINAL IMPEDANCE

N/A

TRANSDUCER TYPE

2x 12" LF (4in VC) EU transducer

CROSSOVER FREQUENCY

DSP controlled with selectable presets 48KHz sampling frequency 24 bit AD/DA converter

MAX. SPL (PEAK)

129dB @ 1m (continuous) 135dB @ 1m (peak)

AMPLIFIER TYPE

Class D, single channel amplifier

AMPLIFIER OUTPUT

2400W (continuous)

INPUT

XLR/F 3p combo connector

OUTPUT

XLR/M 3p connector

INDICATORS

Power, signal/preset, Clip

CONTROLS

Master level control, 4 selectable presets

FEATURE

Cooling by convection

AC POWER SUPPLY

Switching power supply, 85-264Vac

AC MAINS CONNECTOR

Neutrik® powerCON, Power-in (blue) / Power-out (grey)

PROTECTION

Over current and short circuit protection, thermal protection, DC output protection and HF protection (amplifier)

CONSTRUCTION

15mm/18mm birch plywood, textured polyurea coating

GRILLE

Custom perforated metal grille w/ acoustic foam

INSTALLATION / RIGGING / FLYING

4 rubber feet, 4 side handles Ø35mm pole mount socket Prepared for stacking

DIMENSIONS (WXDXH)

600x710x440mm 23.62x27.95x17.32

AC MAINS CONNECTOR

51Kg 114.43lb
